Description
The Trevoli UPS range of 3-speed circulator pumps are available in two sizes. These pumps can be used in both open and closed systems and are a canned-rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. UPS pumps are designed for circulation of liquids in heating and air-conditioning systems. Typical applications include one and two-pipe heating systems, under floor heating systems, solar heating systems and more.
FEATURES
- Port to port dimensions: 130mm (UPS-20-60) 185mm (UPS-25-150)
- Maintenance-free
- Low noise
- Low energy consumption
- Corrosion-resistant stainless steel pump housing
TECHNICAL FEATURES
- Enclosure class: IP42
- Insulation class: F
- Duty rating: Continuous
- Liquid temperature range: 0-110°C
- Maximum ambient temperature: 40°C
- Maximum operating pressure: 10 bar
