GRUNDFOS UPS 20-60 N 150
GRUNDFOS UPS 20-60 N 150 - Image 2

GRUNDFOS UPS 20-60 N 150

Enquire about this product
ModelP2(W)In (A) SpeedConnectionPort-to port lenght (mm)
UPS 32-80 N 1801650.982" M180
UPS 32-100 N 1803451.522" M180
UPS 25-80 N 1801650.701 1/2" M180
UPS 25-60 N 180600.281 1/2" M180
UPS 20-60 N 150900.371 1/4" M150

Description

Simple and reliable domestic hot water circulator with stainless steel pump housing, suitable for drinking water. 3 speed switch allows adjusting performance to the system. Typical applications are tank or tankless water heaters systems with hot water return line.

Liquid temperature: N +2°C to 110°C, K -25°C to +95°C
System pressure: Maximum 10 bar
Supply voltage: 1 x 240 Volt 50 Hz
Pumps body: Stainless steel
Control: 3 speed control
