Description
The BJZ series with their proven reliability and excellent self-priming ability makes them ideal for any house or farm water supply system. The Jet and venturi design allows suctions lift up to 8m – great for drawing from rivers, dams & ponds, shallow wells, and underground tanks. Easy to prime.
TECHNICAL FEATURES:
- Max working pressure: 8bar
- Max liquid temperature: +60°c
- Max suction lift: 8m
MOTOR FEATURES:
- TEFC continuous duty motor
- Class B Insulation
- Ambient temperature: ≤50°C
- Internal overload protector
- IP55 protection
CONSTRUCTION MATERIALS:
- Pump casing, seal plate, pump shaft & Impeller: 304 Stainless Steel
- Mechanical seal: Carbon/Ceramic
- Diffuser/Venturi: PPO
- O Rings: EPDM
- Motor mount and casing: Aluminium
