Description
The Bromic Waterboy™ Series 2 Pressure Controller offers complete control of household pumps through hassle-free automation, starting and ceasing water supply in response to demand.
IP65 rated
Large display panel
Heavy-duty 1.5kW controller
Compatible with any above ground or submersible pump
Supplied with electrical lead suitable for use with any 10amp power outlet
Ideal for domestic, irrigation and agricultural applications
Warranty 2 years
Compatible with: 7575101, 7575100, 7575107 and 7575200.
Supersedes product 7575372.
Specifications
Product Number
7575381
Application
For use in domestic, irrigation and agrigultural applications.
Warranty (Years)
2 Years Replacement Warranty
Power
1.5kW
IP Rating
IP65
Supply Voltage (V)
220-240
Max. Current (A)
10
Max. Heated Water / Working Temperature (°C)
60
Max. Working Pressure (bar)
10
Cut-in Pressure (bar)
2.2
Water Type
Clean
Weight (kg)
1.4
Width (mm)
160
Height (mm)
170
Length (mm)
230
Brands
Waterboy
Fuel type
Water
Pumping Capacity
40L, 60L, 80L, 116L
Inlet Connection ( Connector )
M
Inlet Connection ( Thread Size )
1″
Outlet Connection ( Connector )
M
Outlet Connection ( Thread Size )
1″
Capacity ()
40, 60, 80
