Description
This pump is ideal for domestic or farm water supply, providing mains pressure for a large single or multi-level homes and farms. Able to support up to 15 taps running at one time. Fitted with a variable speed constant pressure controller and 18L pressure tank.
SPECIFICATIONS
- Power -2200W – 3 Horsepower
- Single phase with standard NZ 3 pin plug
- Max Flow rate: 166 litres per minute
- Max Pressure: 102 psi
- Max discharge head: 72 metres
- Max suction 1.5m
- Inlet size: 1½ inch BSP (40mm)
- Outlet size: 1½ inch BSP (40mm)
- Built in thermal overload protection
- Insulation class F
- Rated for Continuous duty
- Liquid temperature range: -20 – 70 deg C
- Max operating pressure: 10 bar
- Length: 450mm
- Height (including pressure tank): 760mm
COMMON APPLICATIONS
- Water supply for large / very large homes
- Farm irrigation
- General water transfer systems
- Industrial/commercial applications
- Domestic Household Pumps
FEATURES
- Fitted with a variable speed constant pressure controller (IP54 rated)
- Delivery pressure can be easily adjusted at any time
- Controller provides soft starts to avoid water hammer and related problems
- Pump motor operates at varying speed based on actual demand saving up to 50% electricity usage
- Run Dry Protection
- Corrosion resistant stainless steel construction
- Stainless steel pump housing
- Stainless steel motor shaft
- Stainless steel impellor and intermediate chambers
- Build in thermal overload protection
- Quiet operation
